| Ask Lasest Price | |
| Brand Name : | CS |
| Certification : | CE |
| Price : | Can be negotiation |
| Payment Terms : | L/C, D/A, D/P, T/T |
| Model Number : | FCS-350 |
Product specification
| Specification | ||
| Model | FCS-350 | |
| Applicable optical fiber material | Quartz optical fiber | |
| Use cladding diameter | φ 60 to 1200 µm | |
| Diameter of applicable coating layer | φ 60 to 1500 µm | |
| Clamp type | FC-xx | |
| Stripping length | 1 to 35mm | |
| The blade life | 350×next | |
| Stripping quantity | A single single core | |
Stripping time | Coating stripping action × 4:18s coating stripping action × 8:35s coating stripping action × 16:60s | |
| Overall dimensions | 238*215*193 | |
| Weight | 6.1kg | |
The power configuration | external power supply:ACInput:100 to 240 V (50 to 60Hz) DCoutput:13.5V / 5A Built-in lithium battery:10.8V, 20400mAh | |
| Work environment | temperature:0～＋40℃,humidity:＜95％,altitude:0～5000m | |
| Storage environment | temperature:-20～＋60℃,humidity:＜95％ | |
|
|
