| Brand Name : | Raytool |
| Model Number : | BM111 |
| Certification : | CE |
| Price : | Can be negotiation |
| Payment Terms : | L/C, D/A, D/P, T/T |
BM111 SERIES
High-performance Automatic Focusing Cutting Head
Power Rate:3000W
♦Multiple cover glass protection
Three cover glasses to protect focusing & collimation lens
♦Exellent Dustproof
IP65 class dustproof, patented protection cover glass catridge, ALL-body anti-dust design
♦Auto-focusing
Auto-focusing to reducing human intervention .MAX focusing speed lOm/min, Repeat accuracy 50 ptm.
♦High-Speed Cutting
Cuts 12 mm SUS304 at 0.6 m/min @3000W, Cuts 12 mm Q235 at 1.2 m/min @3000W
Product specification
| Auto focus | |
| Range | +10~-12mm |
| Acceleration | Max 10 m/s2 |
| Velocity | Max 10 m/min |
| Accuracy | 50μm |
| Fiber Interface | QBH,QD |
| Clear | 28 mm |
| Cover glasses | |
| Collimation side | Φ24.9mm * 1.5 mm |
| Focusing side | Φ27.9mm *4.1 mm |
| Collimator Focal length | 100mm |
| Focusing Focal length Aperture | 125mm, 150mm |
| Nozzle Styles | Single, Double, Custom |
Diameter of Nozzle tip | 0.8mm, 1.0mm,1.2mm, 1.5mm,2.0mm, 2.5mm, 3.0mm, 3.5mm,4.0mm, 4.5mm, 5.0mm |
| Assist gas pressure | ≤30 bar |
| Weight | ~5.7 kg |
|
|
