    OEM 3 In 1 Head Fiber Laser Cleaner Machine 2000w 16mm

    Ask Lasest Price
    Brand Name : HW
    Model Number : HC970
    Certification : CE
    Price : Can be negotiation
    Payment Terms : L/C, D/A, D/P, T/T
    • Product Details
    • Company Profile

    OEM 3 In 1 Head Fiber Laser Cleaner Machine 2000w 16mm


    Product features

    ♦Double protective lens design, dustproof better

    ♦Linear spot, welding operation is more simple, high welding firmness, beautiful grain

    ♦The length of copper nozzle is adjustable, the adjustment mode is simple and fast, the structure design is close, and the dustproof grade is high

    ♦Selection of high-quality precision optical components, excellent and stable beam quality


    ♦Compact structure design, high dustproof level


    Product Advantages

    ♦Cool appearance, ergonomic design, comfortable grip

    ♦Adjustable spot size, high welding firmness, and beautiful lines

    ♦Wireless control module, quick adjustment of parameters, one key to complete wire feeding or rewinding

    ♦The light spot can be adjusted to the center position



    Product application

    HW970 handheld laser welding solution is mainly for plane processing applications within 2000W, with high versatility.


    Product specification

    Parameter nameTechnical index
    Maximum applicable laser power2000W
    Optical fiber interface typeQBH
    Focus lens specificationsDia=20mm,F=150mm
    Collimating lens specificationsDia=20mm,F=50mm
    Maximum clear aperture diameter16mm
    Laser wavelength1064nm
    Welding head weight≤1000g
    Maximum external size of welding head (width)47mm
    Nozzle sizeOuter diameter 10mm, tolerance -0.02mm to -0.04mm, length 72.5mm

    Configuration

    NameQuantity
    Handheld laser welding head1 set
    Spare copper nozzle4 pcs
    Spare protection lens5 pcs

    Note: the above table is for standard factory configuration only
