    500AR 1064nm CW Fiber Laser Fiber Coupled Laser Source Single Mode

    Ask Lasest Price
    Brand Name : CS
    Model Number : CS-YSM 500AR 1064nm
    Certification : CE
    Price : Can be negotiation
    Payment Terms : L/C, D/A, D/P, T/T
    • Product Details
    • Company Profile

    500AR 1064nm CW Fiber Laser Fiber Coupled Laser Source Single Mode


    Product specification

    Optical ParametersYSM 500AR
    Operation ModeCW/Modulation
    Polarization StateRandom
    Beam QualityM2<1.1@14µm
    Output Power500W
    Output Fiber Diameter14µm
    Power Range10%~100%
    Output Power Instability(RMS)≤2%
    Center Wavelength1064nm
    3dB Spectral Width<3nm
    Operating Voltage220V
    Operating Frequency50Hz
    Laser Power Consumption<1.5kW
    Output Fiber Length5m(Customizable)
    CoolingWater Cooling
    Dimensions750mm×455mm×170mm
    Weight45kg
    Operating Temperature10℃~40℃
    Storage Temperature-15℃~60℃
    Relative Humidity20%-80%
