Product Description
Our customized beam homogenizer CW fiber laser can meet different requirements for different application.
Nowadays, laser applications are becoming more and more popular. No matter laser lighting, projection, cosmetology, or some high-energy cutting and cleaning, Beam shaping and homogenization are needed.
Product Parameters
Product specification
Optical Parameters | YSM 2000 |
Operation Mode | CW/Modulation |
Polarization State | Random |
Output Power | 2000W |
Output Fiber Diameter | 600µm |
Power Range | 10%~100% |
(RMS) Output Power Instability | ≤3% |
Center Wavelength | 1080±10nm |
3dB Spectral Width | <4nm |
Indicated Light Wavelength | 635nm |
Indicated Light Power | >0.3mW |
Operating Voltage | 380V |
Operating Frequency | 50Hz |
Laser Power Consumption | <6kW |
Output Fiber Length | 10m |
Cooling | Water Cooling |
Dimensions | 760mm×440mm×140mm |
Weight | 60kg |
Operating Temperature | 10℃~40℃ |
Storage Temperature | -15℃~60℃ |
Relative Humidity | 20%-80% |
![]() |
