Product introduction
TY-450NM+/-05NM-3.0W-25C-2PIN-0.22NA diode lasers employing professional coupling technology, that enjoy multiple advantages, e.g., compact design, stable output power, high power, high efficiency and convenient packaging. These laser diode modules can provide solutions for fiber laser applications and direct suppliers.
Product Parameters
♦ Based on single fire spot laser module
♦ High output power 3W
♦ High stability
♦ 0.22NA 105μm core multimode fiber
♦ Parallel weld 2-Pin sealed package
♦ Standard central wavelength 450nm
♦ RoHS compliance
Product Application
♦ Medical
♦ Printing
♦ pump source
♦ Material processing
Product specification
| Parameter | Min | Typ | Max | Unit | Conditions |
| Output Power | - | 3 | - | W | |
Centre Wavelength T1 | 445 | 450 | 455 | nm | |
| Spectral Width (FWHM) | - | 3 | 7 | nm | |
| Threshold Current | - | 0.25 | - | A | |
| Operating Current | - | 2.65 | 3.0 | A | |
| Operating Voltage | - | 4.6 | 5.5 | V | |
| Convention Efficiency | - | 20 | - | % | |
| 90% Power | - | 0.15 | - | NA | |
| Wavelength shift vs. Temperature | - | 0.1 | - | nm/℃ | |
| Slop Efficiency | - | 1.0 | - | W/A | |
| Storage Temperature | -30 | - | 70 | °C | Non-Condensing |
| Operating Temperature | 15 | 20 | 25 | °C | |
| Fiber Bend Radius | 37.5 | - | - | mm | |
| Buffer Diameter | - | 250 | - | μm | |
| Cladding Diameter | - | 125 | - | μm | |
| Core Diameter | - | 105 | - | μm | |
| Numeric Aperture | - | 0.22 | - | NA | 0.15 |
| Fiber Connector | - | CO | - | SMA905,FC,ST |
|
