| Brand Name : | CS |
| Model Number : | EB-DDLF-2000A/3000A |
| Certification : | CE |
| Price : | Can be negotiation |
| Payment Terms : | L/C, D/A, D/P, T/T |
Product Features
♦ High Efficiency
♦ Red Indicator
♦ Long lifetim
Product application
♦ Metal heat conduction welding
♦ Hybrid welding
Product specification
| Unit | EB-DDLF-2000A | EB-DDLF-3000A | |
Optical | |||
| Center Wavelength | nm | 976±20(915 Can be customized) | |
| Output Power | W | 2000 | 3000 |
| Output Power Unstability | % | ≤3 | |
| Power Tunability | % | 10-100 | |
| Fiber Core | μm | 400/600/800 | |
| Numerical Aperture | NA | ≤0.22 | |
| Fiber Connector | - | QBH | |
| Fiber Length | m | 10/20 ( Can be customized ) | |
| Aming Beam | |||
| Indicator Wavelength | nm | 650 | |
| Output Power | mW | 2 | |
| Eletrical | |||
| Modulate Frequency | - | CW | |
| Operation Mode | Hz | 100(Pulse modulation cannot be greater than 100Hz) | |
| Input Voltage | - | 380VAC±10%,50/60HZ | |
| Input Power | kW | 4.6 | 6.9 |
| Thermal | |||
| Operating Temperature | ℃ | 5-40 | |
| Storage Temperature | ℃ | -25-55 | |
| Environmental Humidity | - | 70%@25℃ | |
| Cooling System | - | Water Cooling | |
| Others | |||
| Dimension | mm | 945×470×138(With the handle) | |
|
|
